STABILISER FOR LARGE SIZE TIPPERS

STABILISER
FOR “LARGE SIZE” TIPPERS

SACMI for enhanced process control and quality

Kit composed of 2 separate supports for the “LARGE SIZE” TIPPER (installed on the RPR Series 700, manufactured from 2006 to 2018), which guarantee perfect horizontal alignment and stability after rotation.
This result is obtained by means of a pneumatic cylinder connected to a lever mechanism that activates a punch: after activating the cylinder, the punch stops against the bottom side of the tipper assembly hence stabilising it.

YOUR ADVANTAGES

  • Perfect mechanical stabilisation of the tipper at the end of a rotation cycle
  • Fewer rejects in high speed operating conditions
  • Less tipper adjustment requirements

WHERE TO INSTALL IT:

RPR - PRESS RECEPTION UNIT - SERIES 700
716 (PH l.c. 1750mm) with tipper for “Large Sizes”
721 (PH l.c. 2250mm) with tipper for “Large Sizes”
723 (PH l.c. 2450mm) with tipper for “Large Sizes”



THE SYSTEM INCLUDES:
